This is a main part of the switching system for a prototype 5 channel amp I patched it together as an external switcher for the amp show display. the footswitch is Remote with 7 buttons a stereo cable to the switchbox carries power ground and data. Originally designed to be wireless an addition of a battery and a wireless transmitter will work. The receiver would need a mod to restore the data to ttl level to work with this exact box. The controller can be made as small as a membrane pad with 7 buttons placed on the guitar itself.
This demo unit switches 5 amps with 2 loops programmable individually to the 5 channels.
One more Demo unit coming switches 5 heads (input and speaker out) thru 2 different cabs with one front end loop. speakers and loop programmable individually to each of the 5 heads via footswitch.
